Gates G25930-0808 (8G-8FJISX) Female Japanese Industrial Standard Swivel (MegaCrimp)
SKU: G25930-0808Cross reference: G259300808TEXF2-0808-JISSUPC/EAN: 072053172379
Female Japanese Industrial Standard Swivel (MegaCrimp)






$20.70
EachUsually ships within 3 days
Product Details
The patented “C” insert pre-assembled MegaCrimp coupling gives world-class, leak-proof performance. It is designed with a patented “C” insert attached to the ferrule that accommodates hose of different constructions and wall thicknesses. The insert’s design ensures crimping forces are evenly distributed to form a concentric seal. The “C” insert simplifies inventory requirements since one MegaCrimp coupling size can accommodate various hose outside diameters, on both one- and two-wire braid hydraulic hose.
- Robust “bite-the-wire” crimp
Specifications
| SKU | G25930-0808 |
|---|---|
| Cross reference | G259300808, TEXF2-0808-JISS |
| UPC/EAN | 072053172379 |
| Coupling Style | MegaCrimp Couplings |
| Swivel | Yes |
| Thread Configuration | Female Japanese Industrial Standard (FJIS) |
| Inside Diameter | 1/2" (08) |
| Bend Angle | Straight |
| Seal Type | Mated Angle |
| Thread Size | 1/2" (08) |
| Gates Code | G25 |
