Velvac 016283 90 DEG. ELBOW UNION 1/4"

The Velvac Push-Lock Air Brake Fitting, Union 90° Elbow is designed for connecting ¼” SAE J844 nylon tubing. Featuring a high-strength composite body, it offers weight savings compared to brass fittings while maintaining excellent durability. Compliant with DOT 49 CFR 571.106 and SAE J1131 standards, this fitting ensures reliable and leak-free performance. The 90° elbow design is ideal for tight spaces, and the engineered tube retention system provides superior holding strength. The positive release bushing makes tubing installation and removal quick and easy. With a temperature range of -45°F to +140°F and a maximum operating pressure of 145 psi, this fitting is perfect for commercial vehicle applications.

Velvac Push-Lock Air Brake Fitting, Union 90° Elbow, ¼” (016283)

PRODUCT OVERVIEW

The Velvac Push-Lock Air Brake Fitting, Union 90° Elbow is engineered to provide secure, reliable connections for ¼” SAE J844 nylon tubing in air brake systems. Its durable composite construction delivers significant weight savings over traditional brass fittings, contributing to increased fuel efficiency and reduced vehicle load. This fitting is compliant with DOT 49 CFR 571.106 and meets SAE J1131 performance standards, ensuring safety and reliability in commercial applications. The 90° elbow design makes it ideal for confined spaces where straight fittings may not fit, offering easy routing and installation. The engineered tube retention system and seal design ensure exceptional holding strength and side load retention. Additionally, the positive release bushing allows for easy insertion and removal of tubing, reducing labor time and ensuring a secure, leak-free connection. With an operating temperature range from -45°F to +140°F and a maximum pressure capacity of 145 psi, the Velvac Union 90° Elbow is built for long-lasting performance.

KEY FEATURES:

• Designed for use with SAE J844 nylon tubing
• Fits ¼” tubing configurations
• 90° elbow design for easy installation in tight spaces
• High-strength composite body for weight savings and durability
• Compliant with DOT 49 CFR 571.106 and SAE J1131 standards
• Operating temperature range from -45°F to +140°F
• Maximum operating pressure of 145 psi
• Engineered tube retention system for secure holding and side load retention
• Positive release bushing for quick and easy tubing insertion and removal
• Ideal for commercial vehicle brake systems and air brake applications
