Velvac 016294 COMP FIT-M.BRANCH"Y"1/4 T.X 1/4 PPRE

The Velvac Push-Lock Air Brake Fitting, “Y” Male Branch offers a secure connection for ¼” x ¼” SAE J844 nylon tubing. Compliant with DOT 49 CFR 571.106 and SAE J1131 standards, it features a high-strength composite construction for weight savings without compromising durability. The built-in swivel allows easy positioning, while the engineered tube retention system ensures superior holding strength. With a temperature range of -45°F to +140°F and a maximum operating pressure of 145 psi, this fitting is ideal for commercial applications.

Velvac Push-Lock Air Brake Fitting, “Y” Male Branch, ¼” x ¼” (016294)

PRODUCT OVERVIEW

The Velvac Push-Lock Air Brake Fitting, “Y” Male Branch is designed to deliver reliable performance in commercial vehicle brake systems. Built to connect ¼” x ¼” SAE J844 nylon tubing, this fitting features a lightweight composite body that offers excellent durability and corrosion resistance. Its DOT 49 CFR 571.106 compliance and adherence to SAE J1131 standards ensure safe and reliable operation. The “Y” Male Branch design includes a built-in swivel feature, providing flexibility during installation and allowing easy alignment in confined spaces. The engineered tube retention system and seal design ensure a secure, leak-free connection with exceptional side load retention. Additionally, the positive release bushing enables quick tubing insertion and removal, reducing installation time and effort. With a temperature range from -45°F to +140°F and a maximum operating pressure of 145 psi, the Velvac Push-Lock Air Brake Fitting, “Y” Male Branch is built to withstand the demands of heavy-duty applications.

KEY FEATURES:

• Designed for use with SAE J844 nylon tubing
• Fits ¼” x ¼” tubing configurations
• “Y” Male Branch design with a built-in swivel for flexible positioning
• High-strength composite body for significant weight savings
• Compliant with DOT 49 CFR 571.106 and SAE J1131 standards
• Operating temperature range from -45°F to +140°F
• Maximum operating pressure of 145 psi
• Engineered tube retention system for superior holding and side load retention
• Positive release bushing for quick and easy tubing insertion and removal
• Leak-free performance for reliable brake system connections
